Why invest in this multi-function labeling machine?
- Save labor costs: One person can operate, doubling or tripling productivity compared to manual methods.
- Can label a variety of products: From round bottles, square bottles to flat bottles; from flat to slightly curved surfaces.
- Optimize space: Compact machine size, suitable for factories with limited area.
- Increase product professionalism: Precise, beautiful labels help enhance brand image.
Main specifications:
| Specification | Value |
|---|---|
| Labeling accuracy | ±1 mm (excluding product and label errors) |
| Labeling speed | 10-20 stamps/min (depending on product and label size) |
| Applicable product dimensions | – Round bottle: max Ф90mm (1-sided labeling) – Square bottle: max Ф100mm (1 or 2-sided labeling) – Flat bottle: max Ф100mm (1,2,3 or 4-sided labeling) – Surface: Flat or slightly curved |
| Applicable label sizes | Length: Optional due to 360° rotation Width: 150mm stamp size – stamp holder |
| Power consumption | Voltage: 220VAC Frequency: 50HZ Power: 550W |
| Required air pressure | 0.4 – 0.7 Mpa |
| Label Roll Request | Roll decal label Outer diameter: Ф260mm Inner diameter: Ф76mm |
| Machine size (LxWxH) | About 1000mm x 470mm x 950mm |
| Machine Weight | About 85kg |
| Machine configuration | – PLC central controller – Touch screen – Automatic sensor, 360° rotation axis |
Accessories included with the machine:
- 01 set of machine adjustment tools
- 01 pedal, 5m air hose
- 01 set of product holder
Optional accessories (purchased separately):
- Indate set: Print NSX, HSD, Lotno on label
- Internal sensor set: Support transparent labeling
